Propeller pitch measuring machine type B The unique measurement system uses the cross arm deflection suppression technology to effectively improve the measurement accuracy.

Product Description

LJG series polar coordinate measuring machine is mainly used for the detection of form and position tolerances of large and medium-sized rotating and helicoidal bodies. It is especially suitable for various propeller manufacturers to measure the radius and pitch of various types of propellers. The product won the third prize of the State Administration of Quality Supervision, Inspection and Quarantine in 2003 and the support of the National Small and Medium Enterprise Innovation Fund.

◆The unique measurement system of the cross arm deflection deformation suppression technology effectively improves the measurement accuracy.

◆Fully automatic balancing tracking system effectively eliminates the precision error caused by the intermittent axis system.

◆Select high IP protection precision displacement sensor to meet the use requirements of the on-site environment.

◆Equipped with professional self-centering chuck components to organically unify the measurement coordinate system and the processing coordinate system.

◆Equipped with data interface and data acquisition software to facilitate data storage and analysis.

Technical Indicators

Unit: mm

Application fields
